x509 Certificate Manual Signature Verification

While going through the manual of openssl, I thought it would be a good exercise to understand the signature verification process for educational purposes. As a fruit to my labor, I would also develop a simple script to automate the process.

What Does “Signing a Certificate” Mean?

A Certificate Authority (CA) utilizes asymmetric cryptography to form a key pair. This key pair is usually referred to as the public key and the private key. Messages encrypted with one key, can only be decrypted with the other key. The public key is advertised and known to all, however the private key is kept secret and should only been known by the CA. When a Certificate Authority (CA) signs a certificate, what it actually does is hash the certificate then encrypt that hash with it’s private key. This hex code is then embedded into the certificate along with information on how it was derived called the Signature Algorithm. Therefore, in order for one to verify that a certificate was signed by a specific CA, we would only need to possess the following:

  • the public key of the CA (issuer)
  • the Signature and Algorithm used to generate signature

The Verification Process

Obtaining the two listed items above is not a difficult task. Let’s examine how we would do this manually

Obtaining the Issuer’s Public Key

The issuer of a x.509 certificate should have it’s own x.509 certificate (that’s also signed if it’s an Intermediate CA, or slef signed if Root CA) to prove it’s authenticity. Once obtaining this certificate, we can extract the public key with the following openssl command:

openssl x509 -in /tmp/rsa-4096-x509.pem -noout -pubkey > /tmp/issuer-pub.pem

Extracting the Signature

Now let’s take a look at the signed certificate. The signature (along with algorithm) can be viewed from the signed certificate using openssl:

openssl x509 -in /tmp/ec-secp384r1-x509-signed.pem -noout -text
...
Signature Algorithm: sha384WithRSAEncryption
     ad:cd:dd:71:cf:8a:79:2c:2d:86:5b:a2:08:7e:00:e0:28:30:
     17:f3:b0:75:a6:12:46:fc:f8:75:9c:4a:57:2f:89:f9:8a:c6:
     03:e4:58:fa:c4:53:13:a7:67:18:60:17:fc:0d:e4:1a:ba:86:
     fd:14:a7:a5:cb:98:a3:d3:ea:40:a8:71:eb:cd:07:b7:e3:16:
     33:8d:ad:45:9f:ca:c7:ca:77:0a:ec:10:42:2a:85:8d:79:de:
     f0:a8:af:38:bc:70:2d:c1:5c:d7:b7:bb:a3:e8:5c:44:d3:89:
     a6:f0:00:8a:b7:1f:df:fd:5b:2a:9e:d3:9c:5f:ec:ad:7a:b8:
     5b:3b:6c:f5:8a:9c:4f:e5:84:d1:c9:ba:af:d5:9c:75:e8:43:
     17:2f:3c:be:e2:49:ef:6a:e1:28:73:f6:57:aa:4e:ec:a3:f9:
     7d:6f:c5:ce:83:20:fc:51:e0:3b:9f:7b:51:06:d3:29:28:08:
     19:99:2b:ca:fb:9e:7c:e9:5e:38:89:ec:71:f8:a4:aa:be:e0:
     1f:65:ed:24:d7:c0:13:aa:0c:f4:b6:f1:24:62:85:38:ac:05:
     f0:d0:de:69:91:dd:98:9d:9a:46:10:30:ac:6a:6a:20:d5:3c:
     c6:10:b4:2b:aa:d9:38:58:07:f2:41:12:23:45:1c:a8:ca:41:
     11:f2:fd:dd:6f:1a:83:ba:4e:ff:ef:b2:0a:7c:32:9e:0d:6b:
     01:17:76:69:59:9c:25:90:54:3d:08:f3:e9:3d:48:14:11:1d:
     09:59:6e:a9:22:1b:f5:c2:80:ee:4d:e7:f5:df:0a:b2:27:f3:
     05:68:3e:23:99:64:bb:d9:dc:25:95:1a:5f:b5:be:7d:0e:b9:
     47:e4:c6:34:0c:22:0a:ad:d0:c5:f9:be:cb:e3:c9:ca:71:d3:
     ea:f6:62:33:2f:08:c4:1e:d6:1e:aa:4b:5c:dd:bc:66:43:18:
     d9:56:68:93:cd:3a:ef:51:b3:67:8a:e9:bd:07:04:95:23:10:
     6c:42:2e:0d:28:a8:b4:c1:81:ba:1b:7e:9d:5c:48:16:6c:04:
     de:53:e6:7d:aa:cb:52:dd:8f:55:8d:09:1f:cf:32:70:ec:81:
     ea:00:07:52:8d:95:2b:b8:b6:ac:b6:36:0a:fd:02:f3:0e:42:
     20:1f:ce:1b:ba:c7:f4:aa:01:53:fb:af:9c:b5:e2:d5:61:7e:
     3c:2b:16:de:22:2b:43:13:f8:5a:6e:ab:c2:0a:85:96:6f:7b:
     b3:ef:49:0f:5f:bf:01:e9:52:f8:de:44:12:23:f5:e6:78:de:
     f6:e0:40:8e:97:89:45:92:f7:73:ee:41:71:7a:7c:de:79:10:
     f2:db:c3:86:85:3c:ac:fe

In the above example, we can tell by the algorithm name sha384WithRSAEncryption that SHA-384 is the cryptographic hash function used and that it was encrypted via RSA.

We can take this hex and dump it to disk as a binary like this:

# extract hex of signature
SIGNATURE_HEX=$(openssl x509 -in /tmp/ec-secp384r1-x509-signed.pem -text -noout -certopt ca_default -certopt no_validity -certopt no_serial -certopt no_subject -certopt no_extensions -certopt no_signame | grep -v 'Signature Algorithm' | tr -d '[:space:]:')

# create signature dump
echo ${SIGNATURE_HEX} | xxd -r -p > /tmp/cert-sig.bin

Decrypting the Signature (RSA)

Now that we have both the encrypted dump of the signature as well as the public key of the issuer. We can decrypt the signature like so:

openssl rsautl -verify -inkey /tmp/issuer-pub.pem -in /tmp/cert-sig.bin -pubin > /tmp/cert-sig-decrypted.bin

We can now finally view the hash with openssl

openssl asn1parse -inform der -in /tmp/cert-sig-decrypted.bin
0:d=0  hl=2 l=  65 cons: SEQUENCE
2:d=1  hl=2 l=  13 cons: SEQUENCE
4:d=2  hl=2 l=   9 prim: OBJECT            :sha384
15:d=2  hl=2 l=   0 prim: NULL
17:d=1  hl=2 l=  48 prim: OCTET STRING      [HEX DUMP]:0C8EDBABEA1EAF2DB57A2A7CC29E2AAA9103167659572DFE10C0D7FF62BA74EC5481D6F049B956775E2BA3E11C5A046A

The digest is in the last line: 0C8EDBABEA1EAF2DB57A2A7CC29E2AAA9103167659572DFE10C0D7FF62BA74EC5481D6F049B956775E2BA3E11C5A046A

Hashing the Original Signature

Now that we got a hash of the orginal certificate, we need to verify if we can obtain the same hash by using the same hashing function (in this case SHA-384). In order to do that, we need to extract just the body of the signed certificate. Which, in our case, is everything but the signature. The start of the body is always the first digit of the second line of the following command:

openssl asn1parse -i -in /tmp/ec-secp384r1-x509-signed.pem
    0:d=0  hl=4 l= 856 cons: SEQUENCE
    4:d=1  hl=4 l= 320 cons:  SEQUENCE
...

We can extract this data and store it to disk like so:

openssl asn1parse -in /tmp/ec-secp384r1-x509-signed.pem -strparse 4 -out /tmp/cert-body.bin -noout

Finally, we can run this through the same hashing function to determine the digest

openssl dgst -sha384 /tmp/cert-body.bin
SHA384(/tmp/cert-body.bin)= 0c8edbabea1eaf2db57a2a7cc29e2aaa9103167659572dfe10c0d7ff62ba74ec5481d6f049b956775e2ba3e11c5a046a

As you can see, both hashes match, so we can now confirm that:

/tmp/rsa-4096-x509.pem did sign /tmp/ec-secp384r1-x509-signed.pem

The Finished Script

Now that we went through that manual process, I have put together a script which undergoes a similar process to determine the valididty of a signature. Now in the real world, your browser will be tasked with validating a chain of certificates not just the certificate that signed your domain’s cert. This script only checks if CERT A signed CERT B.

This script should not be relied upon in any shape, way or form. Simply educational.

Here is an example of how to use this script

# supply the signed cert (-s) and issuer's cert (-i) in pem encoding
sh x509-cert-sig-verify.sh -i /tmp/rsa-4096-x509.pem -s /tmp/ec-secp384r1-x509-signed.pem

Issuer Certificate: /tmp/rsa-4096-x509.pem
Signed Certificate: /tmp/ec-secp384r1-x509-signed.pem
Verified OK

# when no arguments supplied
sh x509-cert-sig-verify.sh
  Missing REQUIRED option -i <ISSUER_CERTIFICATE>

  usage: x509-cert-sig-verify.sh [OPTIONS...]

  -i issuer-cert  required  path or url of issuer x509 cert
  -s signed-cert  required  path or url of signed x509 cert
  -v              optional  verbose logging

  *WARNING*
  This script was made for educational purposes.
  VERIFICATION MAY BE WRONG, USE AT YOUR OWN RISK!

If you made it this far down the post, you are awarded the source of the script!
